A FastAPI agent API with SSE, fail-closed auth, and redacted reads

An agent run takes minutes and produces progress the caller wants to see. That makes the API design different from a normal request-response service in three ways: the response is a stream, the auth model has to work on that stream, and the public read surface leaks more than you expect unless you deliberately trim it.

This is how the Swarm 357 FastAPI runtime handles all three.

SSE, because the traffic is one directional

Agent progress flows one way. The client sends a task and then listens. WebSockets give you bidirectional messaging you do not need, at the cost of upgrade handling in every proxy between you and the user.

Server-sent events are a plain HTTP response with a content type. Proxies, load balancers, and CDNs handle them as HTTP, and browser clients get reconnection for free.

Two implementation details that matter more than the protocol choice:

The stream must end explicitly. A stream that just stops leaves the client unsure whether the run finished or the connection dropped. Swarm 357 emits a stream.end event, and the event bus closes on terminal run state. A client that sees stream.end knows it has everything.

Cancellation must be observable on the stream. When a run is cancelled, cancel_requested is persisted onto the checkpoint rather than held in memory, so the state is visible from any process. See durable checkpoints, resume, cancel, and replay.

Auth that fails closed

The rule is short: if SWARM_API_KEY is set, SSE and write endpoints require it, and production auth is fail-closed.

Fail-closed means an error in the authentication path is a refusal, not a fallback. The anti-pattern is a try around the auth check with an unauthenticated path in the except, which turns any transient failure into an open door. If the check cannot run, the answer is no.

For a public endpoint that a browser reaches, put a backend-for-frontend on your own origin between the browser and the API. That is the only place a write key is read, and it never crosses into client code. The site does this, and the key never enters the build. See deploying a Claude agent runtime on Railway for the build-time side of that.

Public reads, redacted

GET /api/swarm/runs without authentication returns redacted telemetry. Not blocked, redacted, and the distinction is deliberate.

Blocking the endpoint entirely would be simpler and would also remove a legitimately useful public surface. Redaction keeps the health signal and drops the payload.

The same instinct applies to /api/health. A public health endpoint should say the service is alive and which version is running. It should not enumerate configuration, dependency hosts, or feature flags, because that is a reconnaissance gift for the cost of a curl.

The interactive explorer is a choice, not an accident

FastAPI serves /docs, /redoc, and /openapi.json. Leaving them public is intentional here: every route they list is already public in the repository, writes fail closed without the key, and reads are redacted. The explorer tells an attacker nothing the source does not.

If route enumeration matters for your deployment, set SWARM_DISABLE_API_DOCS=1 and all three return 404.

That is the right shape for a security toggle. A default that is defensible, a documented reason, and one variable to change it.

Protecting an unauthenticated demo

A public demo endpoint is an unauthenticated path that spends money. Every control has to be server-side, because a client-side limit is a suggestion.

• Force simulation. Pin simulate: true in the backend-for-frontend regardless of the request body.
• Clamp the budget. Whatever number arrives, clamp it to the demo cap.
• Cap the body. Oversized requests get 413 before parsing.
• Bound the input. A server-enforced character limit, mirrored in the UI so the two agree.
• Rate limit per IP. A sliding window returning 429.

Also set CORS to the origins you actually serve, and let it fail closed when the allowed-origins variable is missing. A permissive default that only tightens when configured is a default that ships wrong.

Status of the surface

The HTTP API, SSE, and HITL approvals are all Beta on the status page. The Bash gate and filesystem confinement underneath are Stable. Distributed rate limiting across replicas is not implemented; the limiter is single-process, and stacking per-process limits is not the same guarantee.

When not to run the API

• Single-machine batch work. Use the CLI. An HTTP surface is attack surface you are not using.
• You cannot own the auth story. If nobody will rotate the key or watch the logs, do not expose it.
• You need multi-tenant isolation. Not implemented, and a shared key is not a tenancy model.

Run it

pip install techtide-swarm
swarm init
swarm serve

Read API overview for the routes, authentication for the key model, SSE event stream for the event shapes, rate limits for the limiter, and streaming events for the client side.
